Specifications:

• HF capacity 8kW
• Welding area 320 cm2 maximum welding surface
• Controlled by compressed air
• Electrode safety (anti-flash)
• Two-handed safety controls for press.
• Table of 750×12000 mm, with large gutter behind
• Pneumatic Toolholder for tool fixing
• Maximum Tool lenght (Electrode) 1000 mm
• Room behind from center electrode 750 mm
• Siemens PLC automation
• Automatic Power setting
• Power supply 3 x 400 Volt+N / 32 Amp connection.
• Welding pressure adjustable up to 1200 kg max. at a minimum of 7 Bar compressed air pressure.
• 15 Metres connection cable and air hose
• Weight 1250 kG
